Brand

Hikvision

Product Type

Bullet Camera

Product Code

DS-2CD1023G0-IUF

General

Linkage Method

Upload to FTP/memory card, notify surveillance center, send email, trigger recording,
trigger capture

Camera Material

Metal & Plastic

Storage Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)

Startup And Operating
Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)

Web Client Language

English, Ukrainian

General Function

Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

Firmware Version

V5.5.120

Power Consumption And Current

12 VDC, 0.4 A, max. 5 W
PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.15 A, maximum. 6.5 W

Power Supply

12 VDC ± 25%
PoE: 802.3af, Class 3

Power Interface

Ø 5.5 mm coaxial power plug

Camera

Image Sensor

1/2.7" Progressive Scan CMOS

Minimum Illumination

Color: 0.01 Lux (F2.0, AGC ON), B/W: 0 Lux with IR

Shutter Speed

1/3 s to 1/100, 000 s

Slow Shutter

Yes

Wide Dynamic Range

Digital WDR

Day & Night

IR Cut Filter

Angle Adjustment

Pan: 0° to 360°,tilt: 0° to 180°,rotate: 0° to 360°

Lens

Focal Length & FOV

2.8 mm, horizontal FOV 112.1°, vertical FOV 60.0°, diagonal FOV 132.2°
4 mm, horizontal FOV 90.2°, vertical FOV 48.6°, diagonal FOV 107.6°

Lens Mount

M12

Focus

Fixed

Aperture

F2.0

Illuminator

IR Wavelength

850nm

IR Range

Up To 30 m

Video

Maximum Resolution

1920 x 1080

Main Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)

Sub Stream

50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)

Video Compression

Main Stream: H.265/H.264
Sub-Stream: H.265/H.264/MJPEG

Video Bit Rate

32 Kbps to 8 Mbps

H.264 Type

Baseline Profile/Main Profile/High Profile

H.265 Type

Main Profile

H.264

Main Stream supports
